AU115F luminaire is made of 5 parts:
THE CROWN
Made of cast aluminium fixed to the TOP COVER.
THE TOP COVER
Made of die cast aluminium insures the overwhole protction of the luminaire.
THE BODY
Made of die cast aluminium. The frame is attached by means of an hinge and 1 S/S screw, under the body, assureing and easy access to the control gear and lamp.
THE OPTIC SYSTEM
It comprises a pure refined aluminium reflector, stamped out in one piece and polished which is attaqched to the frame, and another CDG steel reflector fixed with aluminium reflector. A arc tempered glass or methacrylate diffuse is sealed directly to the CDG steel reflector by means of a silicone seal insuring a high degree of protection.
THE BRACKET
Made of cast aluminium fixed to the BODY. The bracket shape on your request.
⚡ Painted by polyester powder, color on request.
Technical Specifications
Protection Degree
Optical block IP65
Shock Energy
2 Joules (polycarbonate bowl)
Electrical Insulation
CLASS I (CLASS II on request)
What materials are used to construct the AU115F luminaire body?
The body, top cover, crown, and bracket of the AU115F luminaire are constructed from high-quality cast and die cast aluminium to ensure durability and overall protection.
How is maintenance and lamp replacement accessed?
Maintenance is made simple and easy. Access to the control gear and lamp is assured via a frame attached by a hinge and secured with one stainless steel (S/S) screw located under the body.
What components make up the optical system?
The optical system consists of a polished, single-piece stamped refined aluminium reflector attached to the frame, along with a CDG steel reflector. It features either tempered glass or a methacrylate diffuser sealed with silicone.
What is the ingress protection (IP) rating of the optical block?
The optical block of the AU115F luminaire features a high-degree protection rating of IP65.
Can I customize the color and brackets of the luminaire?
Yes, the bracket shape can be customized based on your requests. Additionally, the surface is painted with polyester powder, with colors available upon request.
What electrical insulation classes and impact resistance ratings does it support?
The luminaire comes standard as Class I (Class II is available on request) and is rated for a shock energy of 2 Joules when equipped with a polycarbonate bowl.
