Made of INJECT aluminium body fixed to the dome by means of 1 steel piping fixed (male) 26mm.
Made of INJECT aluminium body. Once removed, the dome and control gears are easily attained.
Made up of 3 aluminium INJECT parts. A ring in aluminium sheet supported by 4 ribs in aluminium sheet fixed to the base flange. Mounting for 26mm held.
Made up of 3 parts sealed together so as to obtain a high degree of protection.
| PROTECTION DEGREE | IP33 (Optical block IP65 available on request) |
| SHOCK ENERGY | 2 joules (PC diffuser) |
| ELECTRICAL CLASS | CLASS I (CLASS II available on request) |
The AU6001A is constructed of four main parts: the finial top, the dome, the frame, and the optical block.
The finial top features an injected aluminium body that is fixed to the dome using one 26mm male steel piping.
The standard options include an Opal or Clear PC (polycarbonate) diffuser. Tempered glass can also be provided on request.
The standard protection rating is IP33. However, an optical block with an IP65 protection rating is available on request.
The luminaire standard configuration is Class I, with Class II options available upon request.
Once the dome and the finial top are removed, the control gear mounted on the CDG steel sheet can be easily attained.
