Product Description

Product Specifications
Series AST115V1, AST115V2, AST115V3, AST115V4
Material Aluminium body + PC
Input Voltage 120-277Vac
Working Current 700mA
Power Factor 0.96
LED Q'ty 16-64pcs
Total Consumption 35W-140W
Efficacy >97 lm/w
LED Chips Cree XPG2
Beam Pattern A01, A02, A03
Color Rendering Index More than 75
Pipe Mounting Dia 48~60mm
IP Rating IP65
Working Condition Temp: -40℃-55℃, Humidity: 10%-95%
Lifetime More than 50,000 hrs
Key Features
Warranty

5 Years reliable warranty support.

Power Saving

At least 60% energy saving compared to traditional lighting.

Long Life

High quality LEDs built to last for more than 50,000 hours.

Heat Dissipation

Patented heat dissipation design to achieve optimum lighting efficiency.

Modular Design

Directly replaceable module structures to suit various applications.

Lab Tested

Nation listing lab tested in strict accordance with IES standards.

Solid-State

Highly resistant to shocks and heavy vibration environments.

Instant-On

Lights turn on immediately without delay in re-strike.

High CRI

CRI above 75 enhances and brings out natural original colors.

Application

Ideally suited for rural roads, commercial squares, gardens, and villas.

AST115V LED Light Series Specifications and Design
Frequently Asked Questions
What series models are available for this light fixture?

This light is available in four specific series models: AST115V1, AST115V2, AST115V3, and AST115V4, accommodating power consumptions ranging from 35W to 140W.

What is the lifespan and warranty policy of this light?

The product is equipped with high-quality Cree XPG2 LED chips that offer a lifetime of more than 50,000 hours, and it comes backed by a 5-year warranty.

How much energy does this LED system save?

This system achieves at least 60% energy saving compared to traditional lighting systems, with a high efficacy performance of over 97 lm/w.

Can this fixture withstand outdoor and harsh environments?

Yes. It features an IP65 rating with an Aluminium and PC body, and is designed to operate in temperatures from -40℃ to 55℃ and humidity levels of 10% to 95%.

What are the recommended applications for these lights?

The light is designed with A01, A02, and A03 beam patterns and is ideal for installation along rural roads, in commercial squares, gardens, and villas.

What are the pipe mounting size requirements?

This outdoor LED fixture is compatible with mounting pipes that have a diameter of 48mm to 60mm.
